INTRODUCTION INTRODUCTION
The pulse width is adjustable, the spot quality is better, and it is more suitable for fine marking than ordinary optical fibers.
Common areas: aluminum oxide blackening, stainless steel coloring, coating stripping, metal deep carving, etc.
Parameter
| Item | Parameter | |||
| Model | ML-20 | ML-30 | ML-50 | |
| Repetition frequency (KHz) | 1-400 | 1-1000 | ||
| Pulse width (ns) | 200 | 4-250 | 1-250 | |
| Marking speed (mm/s) | <10000 | |||
| Marking range (mm) | 175*175 (default) 150*150 200*200 optional | |||
| Computer and display | Desktop standard configuration: 4U industrial computer with +18.5 inch display, portable: optional notebook, touch computer | |||
| Control card | Genuine high precision laser marking card | |||
| Cooling method | High efficiency air cooling | |||
| Body interface | USB, foot pedal interface | |||
| Power demand | AC 220V/50Hz (default), AC 110V/50Hz (customized) | |||
| Machine power (W) | 500W | |||
| Machine weight (kg) | Standard model: 80KG | |||
| Packing size | Standard model: 700*760*1200mm | |||
